Choosing Between HDMI and DisplayPort for Monitors: Which is Right for You?

Choosing Between HDMI and DisplayPort for Monitors: Which is Right for You?

What is the Difference Between HDMI and DisplayPort?

If you're setting up a new monitor or upgrading your display, you might be wondering: is HDMI or DisplayPort the better option? Both interfaces have their own strengths and are widely used across various devices. HDMI is the default for TVs and many gaming consoles, while DisplayPort is a favorite among PC gamers and professionals. But how do they actually differ, and which one should you choose?

This guide will dive deep into the features of HDMI and DisplayPort, helping you pick the right option for your specific needs.


DisplayPort vs HDMI: How Did They Evolve?

DisplayPort
Introduced in 2006 by VESA, DisplayPort has been continuously updated, with DisplayPort 2.1 as the latest version. It is designed specifically for high-performance displays and includes features like Multi-Stream Transport (MST) for multi-monitor setups and ultra-high resolutions with high refresh rates.
6ft Gold Plated Premium DisplayPort Male to Male Cable with Latches, Version 1.4 VESA Certified

HDMI
HDMI has been around since 2002 and is the most common interface for TVs, projectors, and home theater systems. The latest HDMI version, HDMI 2.1, offers 48Gbps bandwidth, supporting 8K resolution at 60Hz and even 10K displays for future use. HDMI’s ARC and eARC features also make it a strong contender for home audio setups.
10ft Ultra High Speed 8K HDMI Bi-Directional Cable, Certified HDMI 2.1, 8K Support, UL, Black

Which Supports Higher Resolutions and Refresh Rates, DiaplayPort or HDMI?

When it comes to resolution and refresh rate, DisplayPort generally has the edge for high-end displays. DisplayPort 2.1 supports up to 16K resolution at 60Hz or 8K at a blazing 240Hz, making it ideal for high-performance gaming and professional graphics work. HDMI 2.1, on the other hand, caps at 8K at 60Hz or 4K at 120Hz, which is still more than sufficient for most users but falls short for ultra-high-refresh gaming.

Feature DisplayPort 2.1 HDMI 2.1
Max Resolution 16K at 60Hz, 8K at 240Hz 10K at 60Hz, 8K at 60Hz
Max Refresh Rate (4K) 240Hz 120Hz
Ideal Use Case High-end gaming, multi-monitor setups Home theater, mainstream gaming


Does HDMI or DisplayPort Offer Better Audio Support?

HDMI has a clear advantage in audio capabilities, especially with features like Audio Return Channel (ARC) and Enhanced Audio Return Channel (eARC). ARC allows audio to travel both ways between your TV and sound system, eliminating the need for separate audio cables. eARC, introduced in HDMI 2.1, supports even higher-quality audio signals for immersive home theater experiences.

While DisplayPort also transmits audio, it lacks ARC/eARC, making HDMI the go-to choice for users prioritizing audio setups in their home theaters.



Can DisplayPort and HDMI Work with Adaptive Sync?

Both HDMI and DisplayPort support adaptive sync technologies, but DisplayPort has traditionally been more popular for gaming. DisplayPort 1.2 and later versions support Adaptive-Sync (FreeSync), making it perfect for gaming without screen tearing. HDMI 2.1 introduced Variable Refresh Rate (VRR), bringing G-Sync compatibility to HDMI. If you’re a gamer, both options now support adaptive sync, though DisplayPort generally offers higher refresh rates for more demanding setups.

Do You Need Multi-Monitor Daisy-Chaining?

For users looking to connect multiple monitors, DisplayPort is the preferred choice due to its Multi-Stream Transport (MST) capability, which allows you to daisy-chain multiple monitors from a single port. This feature is supported from DisplayPort 1.2 onwards, making it convenient for multi-monitor workstations or complex setups. HDMI lacks daisy-chaining support, meaning each monitor needs its own HDMI connection to the source device.

Feature DisplayPort HDMI
Daisy-Chaining (MST) Supported Not supported
Best For Multi-monitor setups Single displays, TVs, home theaters



Which is Better for Home Theater Systems, DisplayPort or HDMI?

For home theater enthusiasts, HDMI is the clear choice. Its wide compatibility with TVs, soundbars, and AV receivers, coupled with support for ARC and eARC, make HDMI ideal for streamlined audio and video connections. DisplayPort, while excellent for computers and gaming, is less commonly used in consumer home theater setups.
100ft Ultra High Speed 8K HDMI Fiber Optic Cable (AOC), HDMI 2.1, CL3 Rated, 8K Support, UL, Black

Do Cable Length and Quality Affect Performance?

Both HDMI and DisplayPort cables are available in a variety of lengths, but it's essential to consider the quality and specifications, especially if you're dealing with higher resolutions and refresh rates. HDMI 2.1 cables are typically limited to shorter lengths (up to 3 meters) for full 48Gbps bandwidth without quality degradation, whereas DisplayPort cables can support slightly longer lengths at high bandwidths.

For longer distances, both HDMI and DisplayPort offer fiber optic versions, which maintain signal quality over extended lengths, albeit at a higher cost.

DisplayPort vs. HDMI: Which Should You Choose?

In the end, the choice between HDMI and DisplayPort depends on your primary use case:

  • For High-Performance Gaming and Multi-Monitor Setups: DisplayPort offers higher refresh rates, MST daisy-chaining, and robust support for adaptive sync, making it ideal for gaming and professional workstations.

  • For Home Theater and General Consumer Use: HDMI’s ARC/eARC support, compatibility with a vast array of consumer electronics, and widespread use in TVs and gaming consoles make it the preferred choice for home theaters.


Summary Table: Key Differences Between HDMI and DisplayPort

Criteria DisplayPort HDMI
Max Resolution Up to 16K Up to 10K
Max Refresh Rate (4K) 240Hz 120Hz
Adaptive Sync Yes, FreeSync, G-Sync Yes, VRR (G-Sync, FreeSync)
Daisy-Chaining Yes (MST) No
Audio Return (ARC/eARC) No Yes
Best for Gaming, Multi-monitor setups Home theaters, mainstream gaming




Conclusion

Choosing between HDMI and DisplayPort ultimately depends on your unique needs. For high-end gaming setups and multi-monitor configurations, DisplayPort is typically superior. On the other hand, HDMI excels in home theater applications and general consumer devices due to its broader compatibility and enhanced audio support. At Cable Leader, we offer a range of HDMI and DisplayPort cables to meet your connectivity needs. Explore our DisplayPort cables and HDMI cables to find the perfect fit for your setup.
